- 台湾固纬GPC-3060D三组输出直流电源供应器
详细信息
特点 ．三组输出 (两组可调，一组固定电压)
． 自动 Tracking
． 自动串并联操作
． 固定电压与固定电流操作功能
． 低涟波与低杂讯
． 具可选择连续或动态负载
． 过载与极性反向保护功能
．3 1/2 位数 0.5" LED 显示
． 5V, 3A 固定输出规格
OPERATION MODE
Independent (0~30V/0~6A) x 2, (5V/3A Max.) x 1 Series 60V 6A Parallel 30V 12A 5V FIXED OUTPUT
Line Regulation < 5mV Load Regulation < 10mV Ripple & Noise < 2mVrms Voltage Accuracy 5V±0.25V Output Current 3A TRACKING OPERATION
Tracking Error < 0.5% + 10mV of the master Series Regulation < 300mV CONSTANT VOLTAGE OPERATION
Line Regulation < 0.01%+3mV Load Regulation <0.01% + 3mV (rating current <3A)
< 0.02% + 5mV (rating current <10A)Ripple & Noise < 1mVrms 5Hz ~ 1MHz Current Output < 100μS ( 50% load change, minimum load 0.5A ) CONSTANT CURRENT OPERATION
Line Regulation < 0.2% + 3mA Load Regulation < 0.2% + 3mA Ripple & Noise < 3mArms METER
Type 3 1/2 digit 0.5" LED display Accuracy ±( 0.5% of rdg + 2 digits ) INSULATION
Chassis and Terminal 20MΩ or above (DC 500V) Chassis and AC Cord 30MΩ or above (DC 500V) POWER SOURCE AC 100V/120V/220V/240V ±10%, 50/60Hz ACCESSORIES
User manual x 1
Power cord x 1
Test lead GTL-104 x 2 (<10A), GTL-105 x 1(<3A)
European test lead GTL-204 x 2(<10A), GTL-203 x 1(<3A)DIMENSIONS & WEIGHT 255(W) x 145(H) x 346(D)mm
Approx. 18.5kg -
-
