30mΩ, 300mΩ, 3Ω, 30Ω, 300Ω, 3kΩ 30kΩ, 300kΩ and 3MΩ 9ranges |
| ? |
30mΩ: ±1% reading + 6 digits
300mΩ: ±0.05% reading + 6 digits
3Ω: ±0.05% reading + 3digits
30Ω~3MΩ: ±0.05% reading + 2 digits |
| ? |
Hi/Lo, Go/No-Go, Trigger, %, Diode, REL, Temp, TC |
| ? |
7 measuring/sec at 30,000 counts ;
30 measuring/sec at 3,000 counts |
| ? |
Standard: Handler, Scan (same connector)
Option: RS-232C, GPIB |
| ? |
AC 110V, 120V, 220V, 230V±10%, 50/60Hz |
| ? |
电源线x1 ,
操作手册× 1,
测试线 GTL-108A ×1,
Option: PT-100 Temperature Probe (K-Type) |
| ? |
251(W)×91(H)×291(D) mm
Approx. 2kg |
