- 台湾固纬GDM-396数字万用表
详细信息
特点 - 3999 Counts Auto/Manual Ranging
- High Energy Fuse for 10A Range
- Capacitance, Frequency Measurement
- Continuity Beeper/Diode Test
- Data Hold/Relative Mode
- True RMS/RS232C
规格
DC VOLTAGE
Range 400mV, 4V, 40V, 400V, 1000V Best Accuracy ∮(0.8%rdg + 1digit) Input Impedance 10M AC VOLTAGE (40Hz ~ 400Hz)
Range 4V, 40V, 400V, 750V Best Accuracy ∮(1%rdg + 5 digits) Input Impedance 10M DC CURRENT
Range 400uA,4mA,40mA,400mA,4A,10A Best Accuracy ∮(1%rdg + 5 digits) AC CURRENT (50Hz ~ 400Hz)
Range 400uA,4mA,40mA,400mA,4A,10A Best Accuracy ∮(1.5%rdg + 5 digits) RESISTANCE
Range 400 ~ 40M 6 ranges Best Accuracy ∮(1%rdg + 2 digits) CONTINUITY BEEPER
? Buzzer sounds if conductance less than 70 DIODE TEST
Open Circuit Voltage approx. 1.5V typical CAPACITANCE
Range 40nF,400nF,4F,40F,100F Best Accuracy ∮(3%rdg + 5 digits) FREQUENCY
Range 10Hz ~ 10MHz Best Accuracy ∮(0.1%rdg + 3 digits) TEMPERATURE()
Range -40~1000 Best Accuracy ∮1+3 SPECIAL FUNCTION
? Duty cycle, Auto Ranging ? True RMS, RS232C LCD DISPLAY
? 3999 counts POWER SOURCE Single 9V battery (6F22) ? ? ACCESSORIES
? Instruction manual
Battery
Test leadsDIMENSIONS & WEIGHT 85(W) x 177(H) x 40(D) mm
Approx.330g -
-
