- 台湾固纬GDM-395数字万用表
详细信息
特点 - Slim Pocket Digital Multimeter
- 3999 Counts Auto/Manual Ranging
- Capacitance, Frequency Measurement
- Continuity Beeper/Diode Test
- Data Hold/Relative Mode
规格
DC VOLTAGE
Range 400mV, 4V, 40V, 400V, 600V Best Accuracy ∮(0.7%rdg + 3 digits) Input Impedance 10M AC VOLTAGE (40Hz ~ 400Hz)
Range 4V, 40V, 400V, 600V Best Accuracy ∮(2.3%rdg + 5 digits) Input Impedance 10M RESISTANCE
Range 400 ~ 40M 6 ranges Best Accuracy ∮(2%rdg + 5 digits) CONTINUITY BEEPER
? Buzzer sounds if conductance less than 70 DIODE TEST
Open Circuit Voltage approx. 1.5V typical CAPACITANCE
Range 40nF,400nF,4F,40F,100F Best Accuracy ∮(5%rdg + 10 digits) FREQUENCY
Range 1Hz ~ 99.9kHz Best Accuracy ∮(0.7%rdg + 3 digits) TEMPERATURE()
Range -40~1000 LCD DISPLAY
? 3999 counts POWER SOURCE Cell Battery ? ? ACCESSORIES
? Instruction manual
Battery
Test leadsDIMENSIONS & WEIGHT 56(W) x 110(H) x 11.5(D) mm
Approx.97g -
-
