- 台湾固纬GDM-394数字万用表
详细信息
特点 - 3999 Counts Auto/Manual Ranging
- Capacitance, Frequency Measurement
- Continuity Beeper/Diode Test
- High Energy Fuse for 10A Range
- Data Hold/Relative Mode
规格
DC VOLTAGE
Range 200mV, 2V, 20V, 200V, 1000V Best Accuracy ±(0.8%rdg + 1 digits) Input Impedance 10MΩ AC VOLTAGE (40Hz ~ 400Hz)
Range 2V, 20V, 200V, 750V Best Accuracy ±(1%rdg + 5 digits) Input Impedance 2MΩ DC CURRENT
Range 400uA,4mA,40mA,400mA,4A,10A Best Accuracy ±(1%rdg + 5 digits) AC CURRENT (50Hz ~ 400Hz)
Range 400uA,4mA,40mA,400mA,4A,10A Best Accuracy ±(1.5%rdg + 5 digits) RESISTANCE
Range 400Ω ~ 40MΩ 6 ranges Best Accuracy ±(1%rdg + 2 digits) CONTINUITY BEEPER
? Buzzer sounds if conductance less than 70Ω DIODE TEST
Open Circuit Voltage approx. 1.5V typical CAPACITANCE
Range 40nF,400nF,4μF,40μF,100μF Best Accuracy ±(3%rdg + 5 digits) FREQUENCY
Range 10Hz ~ 10MHz Best Accuracy ±(0.1%rdg + 3 digits) TEMPERATURE(℃)
Range -40℃~1000℃ SPECIAL FUNCTION
Duty cycle, Auto Ranging LCD DISPLAY
3999 counts POWER SOURCE Single 9V battery (6F22) ACCESSORIES
Instruction manual
Battery
Test leadsDIMENSIONS & WEIGHT 85(W) x 177(H) x 40(D) mm
Approx.330g -
-
