| | 品牌：美国CPS | | 材质：不锈钢 | | 驱动方式：气动 | |
| | 功率：看说明 | | 极限压力：看说明 pa | | 外形尺寸：看说明 mm | |
| | 型号：VP8D | | | | | |
VP8D真空泵VP8D美国CPS真空泵VP8D
Item Features:
-
Dual voltage operation 110-120V / 220V 50 / 60Hz
-
Exceptional ultimate vacuum rating as low as 10 microns
-
Advanced air cooled motor design for operation in high ambient temperatures
-
Proprietary oil mist free exhaust port cap for clean, safe job environment
-
Gas ballast valve speeds achievement of deep vacuum
-
Multiple port connections for 1 / 4", 3 / 8" and 1 / 2" ACME
-
Easy maintenance with large oil sight glass and fill port with easily accessible oil drain port
-
Solid rubber base provides extreme shock resistance
-
Sure grip handle ergonomically designed for superior comfort and portability
Item Features:
Power: 110V-120V / 220V 50 / 60 Hz USA plug
Stage: 2
Motor Size (HP) RPM @ 50 / 60 Hz: 1 / 2 (HP) 2880 / 3440 RPM
Dimensions: 14.9" x 5.7" x 10.6"
Weight: 22.5 lb / 10.2 kg
Operating Temperature Range: 0 °C (32 °F) to 52 °C (125 °F)
Ultimate Vacuum: as low as 10 microns
Oil Capacity: 29 oz / 860 ml
Overload Protection: Motor thermally protected, dual voltage units have extra IEC fuse
Control System: On-off power switch
Free Air Displacement: 8 CFM @ 60 Hz, 192 l / m @ 50 Hz
Intake Fittings: 1 / 4" SAE, 3 / 8" SAE and 1 / 2" ACME
