VPC2DU真空泵VPC2DU美国CPS

Item Description:

The VPC2DU Premium Compact series of Pro-Set® vacuum pumps incorporate the perfect balance of professional grade performance features in an extremely portable, lightweight package. This innovative 2 CFM, 2 stage unit is factory tested and certified to achieve an ultimate vacuum rating as low as 15 microns and weighs only 12.1 lb / 5.5 kg. Big performance in a small package, the VPC2DU provides fast, deep vacuums without weighing you down.

Key Features:

• Innovative compact and lightweight design weighs only 12.1 lb / 5.5 kg
• Exceptional ultimate vacuum rating as low as 15 microns
• Advanced air cooled motor design for operation in high ambient temperatures
• Proprietary oil mist free exhaust port cap for clean, safe job environment
• Easy maintenance with large oil sight glass and fill port with easily accessible oil drain port.
• Solid rubber base provides extreme shock resistance
• Sure grip handle ergonomically designed for superior comfort and portability
• Extremely compact and portable design

Item Specifications

Model No: VPC2DU

Power: 115V 50/60 Hz USA Plug

Stages: 2

Motor Size (HP) RPM @ 50/60Hz: 1/4 (HP)2880 / 3440 RPM

Dimensions (Inches): 11.3 x 4.5 x 8.0

Weight: 12.1 lb / 5.5 kg

Operating Temperature Range: 0 C (32 °F) to 52 °C (125 °F)

Ultimate Vacuum: as low as 15 Microns

Oil Capacity: 9 oz / 250 ml

Overload Protection: Motor thermally protected

Control System: On-Off power switch

Free Air Displacement: 2 CFM @ 60hz, 48l/m @ 50Hz

Intake Fittings: ¼" SAE and ½"ACME

Gas Ballast Valve: No
